Virtual desktops that are private by construction.
Dedicated virtual machines for every employee. Hardware-encrypted memory. Sub-5ms display. Ransomware recovery in 28 seconds. Open-source stack, zero vendor lock-in.
Virtual desktops that are private by construction.
Dedicated virtual machines for every employee. Hardware-encrypted memory. Sub-5ms display. Ransomware recovery in 28 seconds. Open-source stack, zero vendor lock-in.
The metrics traditional VDI cannot reach.
Standard remote desktop products encode pixels, push them across a network, and decode on the client. That round-trip is where the latency and the compression artifacts come from. We removed it.
One platform. Every control your security team will ask for.
A managed VDI delivered on a KVM/OpenStack hypervisor with OVN networking, Ceph storage, and a Grafana and Wazuh observability stack. Every component is open source.
Dedicated resources
Every user gets 4 NUMA-pinned cores, 8 GB ECC RAM, and 200 GB NVMe. Physical cores, not shared vCPUs.
Encrypted in use
AMD SEV-SNP encrypts VM memory with a unique hardware key. Even the hypervisor admin cannot read it.
eBPF kernel telemetry
Syscall tracing per process, behavioral baselines, anomaly detection. 100–500ns overhead per event.
Ephemeral sessions
Fresh VM cloned from a golden image at every login. On logout, the VM is destroyed and keys rotate.
Data loss prevention
USB allow-lists, clipboard control, print and screen-capture restrictions, outbound keyword scanning.
Ransomware rollback
Immutable ZFS snapshots every five minutes. Auto-detect on high-entropy writes. 28-second restore.
Shadow & control
Live session shadow for support, interactive takeover for incidents, force-logoff for emergencies.
Single sign-on
LDAP, Active Directory, Azure AD, Google Workspace. MFA via TOTP, hardware tokens, email OTP.
Audit-ready trail
Tamper-proof, append-only logs with cryptographic chaining. CEF, JSON, Syslog. Up to 7-year retention.
Seven layers. Each enforces policy on its own.
A compromise at one layer cannot cascade. Hardware roots-of-trust at the bottom, application sandboxing at the top, and independent enforcement at every step in between.
Shared memory, not pixel streaming.
Traditional VDI products encode the desktop to video, push it across the network, and decode on the client. We write display output to a shared RAM region the host reads directly. The result is what users actually notice first.
| Metric | RevInfotech Secure VDI | Traditional VDI (VNC / RDP) |
|---|---|---|
| Display latency | <5ms | 50–100ms |
| Desktop boot time | 125ms | 30–120 seconds |
| Maximum resolution | 4K @ 60Hz | 1080p typical |
| Per-session CPU overhead | Near zero | 15–30% |
| Compression artifacts | None — pixel perfect | Visible on motion |
| Memory encryption in use | AMD SEV-SNP, hardware-enforced | Not standard |
Per user, per month. No hidden meters.
No per-session charges, no bandwidth fees, no API call charges, no storage overage within allocation. Add or remove users every month. Run it on our hardware, your hardware, or both.
For teams that already own their Windows and Office licenses and want the platform underneath.
- Dedicated hardware, no multi-tenancy
- Full seven-layer security stack
- IVSHMEM display, 3-2-1 backup, ZFS snapshots
- Grafana dashboards included
- 24×7 infrastructure support
For teams that want a single line item: OS, productivity suite, third-party patching, and full incident response.
- Windows Server and Desktop licensing included
- Microsoft Office included
- Third-party software patching managed by us
- 24×7 full support plus incident response
- Everything in Standard
Built for regulators, not just auditors.
Tamper-proof logging, configurable data residency, and audit-ready controls aligned to the frameworks your security and legal teams already report against.
Extend the platform when the threat surface widens.
Optional modules layered on the same management plane. Turn them on when you need them, not before.
Blackwall
Remote browser isolation. Firefox runs in a server-side container. Only pixels reach the user. No downloads ever touch the desktop.
GhostWalk
Zero-fingerprint browsing for competitive intelligence. Camoufox with 140+ fingerprint spoofs, residential IP exit, self-hosted SearXNG.
Chhaap
Steganographic credential storage. Passwords hidden inside ordinary images. AES-256 with PBKDF2 at 600K iterations. Offline by design.
Enterprise WAF
Full reverse proxy and WAF for customer-facing applications. OpenResty plus ModSecurity. eBPF XDP DDoS protection. Auto-SSL.
GPU compute
Dedicated GPUs for AI/ML, video editing, and 3D CAD. NVIDIA RTX 4090 and A100, AMD MI210 with SR-IOV. Passthrough or MIG partitioning.
Multi-region
Mumbai, Dubai, Singapore, London, Sydney, Montreal, US-East. Single management plane, per-region data sovereignty.
From kickoff to production in six to eight weeks.
A dedicated project manager, two admin training sessions, end-user documentation, and a 30-day hypercare period. Phased rollout by department with parallel running against legacy.
Eighteen years of building production systems for regulated industries.
RevInfotech is not a reseller. We design, build, and run the infrastructure described on this page. The same engineering team that ships the platform handles your deployment, your audit responses, and your incident calls.
Engineering depth
Our infrastructure team has shipped production deployments across blockchain, fintech, healthcare, and enterprise software for regulated clients in the UAE, India, the United States, Canada, the United Kingdom, and Australia. The Secure VDI platform is built on the same foundations we use for those workloads: KVM, OpenStack, Ceph, OVN, ZFS, eBPF, and Wazuh.
We do not subcontract security work. The seven-layer architecture documented on this page was designed and implemented by RevInfotech staff engineers, not licensed from a third party.
- 100 to 150 engineers across six countries
- 18 years of operation (founded 2008)
- ISO 27001 information security management aligned
- SOC 2 Type II controls aligned
- Deployments in regulated fintech, healthcare, and government sectors
About this document
This page is the public version of the RevInfotech Secure VDI Product Technical Specification v3.0, a document originally written for evaluation by CTOs and engineering leadership. The architecture, performance figures, and SLA commitments shown here are taken directly from that specification.
Where the specification contains commercially sensitive detail (precise SLA credit calculations, minimum-commitment terms, volume discount tiers), this page presents the buyer-facing summary. The full document is available under NDA on request.
What CTOs and CISOs ask before a pilot.
Twelve questions we hear most often from buyers and security teams during evaluation. The answers below are the same ones we give in pilot kickoffs.
Three differences matter. First, display latency: we use IVSHMEM shared memory between the VM and the host, which delivers sub-5ms latency with no encoding artifacts. Citrix, Horizon, and WorkSpaces encode pixels to video and stream them over the network, which lands at 50 to 100ms.
Second, memory encryption: we use AMD SEV-SNP so each VM's RAM is encrypted with a hardware key that even the hypervisor administrator cannot read. The others do not encrypt VM memory in use by default.
Third, licensing: per user, per month, with no per-session metering, bandwidth fees, or storage overage. No vendor lock-in because the entire stack is open source.
Minimum 50 users per deployment and a 12-month commitment with a quarterly review option. After Month 6 you can terminate with 90 days notice and no penalty. You can add or remove users monthly as long as the deployment stays at or above 50 users.
Yes. Three options. Our hardware: we provision and manage dedicated servers, and licensing covers infrastructure. Your hardware: we deploy our software stack on your servers, and licensing covers software and management only at a lower per-user price. Hybrid: a mix of both under one management plane with the same SLAs.
The choice is usually driven by data residency rules or existing capex.
ZFS takes a copy-on-write snapshot of each user's data disk every five minutes. The snapshots are immutable, which means malware running inside the VM cannot delete or modify them.
We also run real-time entropy monitoring via eBPF and Falco. When a process writes a large volume of high-entropy data to disk, we treat that as ransomware behavior and trigger an automatic rollback to the last clean snapshot. The 28-second figure is the full restore time for a 200 GB data disk. RPO is under five minutes.
Yes, with caveats specific to each framework. DPDP Act and RBI data localization are handled by deploying nodes in India and configuring data residency to prevent cross-border transfer. UAE NESA and IAS alignment is configurable per tenant.
ISO 27001 and SOC 2 Type II controls are built into the platform with audit-ready logging. HIPAA and PCI DSS require additional configuration depending on the workload, which our team handles during deployment. GDPR is supported via configurable data residency and tamper-proof audit trails.
All audit logs are append-only with cryptographic chaining and retainable up to seven years.
For a 100-user deployment, TCO over three years typically lands at 35 to 50 percent of equivalent physical workstation cost, depending on the user profile.
The savings come from longer hardware refresh cycles on the client side (thin clients last 8 to 10 years versus laptops at 3 to 4), reduced IT support hours because the desktop image is centrally managed, lower endpoint security spend because the attack surface moves server-side, and zero data loss costs from device theft or loss.
We provide a written TCO model as part of the discovery phase.
Because the entire stack is open source (KVM, OpenStack, OVN, Ceph, ZFS, Wazuh, Grafana, eBPF tooling), there is no proprietary format lock-in.
We provide complete exports of golden images, user data disks, configuration files, and Terraform infrastructure code. You can rehost the stack on your own hardware, transfer to another integrator, or migrate to a different VDI platform. The 90-day post-termination cooperation period is included in the standard contract.
We use a phased rollout over six to eight weeks. Weeks 1 to 2 cover discovery and architecture design. Weeks 2 to 4 build out the infrastructure and golden images in parallel. Weeks 4 to 5 run a 10 to 15 user pilot for performance benchmarking. Weeks 5 to 6 migrate the rest of the user base in batches of 25 to 30, with parallel running against legacy systems for a safety net. Week 6 to 8 is stabilization and support handover with a 30-day hypercare period.
Most users transition without measurable productivity loss because the user experience on day one is indistinguishable from a local desktop.
Yes. Because the desktop runs server side and the client only displays pixels, hardware requirements are minimal. Native clients work on any laptop made in the last decade with 2 GB RAM and 100 Mbps. The browser portal works on Chrome, Firefox, Edge, or Safari at 50 Mbps. Thin clients including Raspberry Pi 4+ work at full performance.
We have deployments in environments with 4G mobile uplinks and the user experience remains usable for light tasks like email and document editing. Heavy workloads like video conferencing and 3D CAD benefit from a dedicated 100 Mbps connection.
Four mechanisms layered together. AMD SEV-SNP encrypts VM memory with a hardware key the hypervisor administrator cannot read, so even root access to the host does not expose user data.
Audit logs are written to append-only storage with cryptographic chaining, so an administrator cannot edit logs to cover tracks. Role-based access control separates user management, server configuration, and audit review across distinct roles with no single super-admin handling all three. Session recording is available for compliance-sensitive roles, capturing screen activity for retroactive review.
The combination makes successful insider abuse measurable and traceable.
Both modes are available per group policy. The default for security-conscious environments is locked down: users get a golden image with a curated application set assigned by their group, and they cannot install new software.
For developer or power-user groups, you can allow installations within the user's data disk while keeping the OS disk read-only and ephemeral. Either way, applications installed centrally on the golden image propagate to all users at next login, and image versioning lets you roll back instantly if an update causes issues.
Schedule a pilot via the contact form on this page or email contact@revinfotech.com. A pilot is typically 10 to 15 users for three to four weeks, with real workloads under production-grade configuration.
We benchmark display latency for your specific applications, validate compatibility with your line-of-business software, produce a written compatibility report, and walk through TCO modeling. Pilots run on RevInfotech hardware so there is no setup cost to your side. Decision usually happens within two weeks of pilot completion.
See it on your own workload.
Schedule a pilot deployment with our engineering team. We will benchmark display latency, run your applications, and produce a written compatibility report before you commit.
